SPRT TL31
Product Description
SPRT TL31 is a high-speed 80mm direct thermal label printer designed for demanding business environments. It combines robust performance with versatile media handling, making it suitable for a wide range of applications from retail labeling to logistics. With its fast print speed and support for various label types and barcodes, it is engineered to enhance operational efficiency and accuracy.
The printer utilizes line thermal printing technology with a resolution of 8 dots/mm (203 dpi), delivering sharp text, graphics, and barcodes. It boasts a maximum print speed of 150mm/s, significantly boosting throughput for high-volume labeling tasks.
Built for continuous operation, its print head has a lifespan of up to 50 kilometers when used with specified thermal paper, ensuring long-term reliability.
It supports paper widths from 40mm to 80mm, with a maximum print width of 72mm and can handle label sizes up to 80mm x 202mm. It accommodates both roll paper and fanfold paper, offering flexibility for different use cases.
The printer supports an extensive set of characters, including GB18030 Chinese, BIG5, and Shift JIS Japanese. It prints all major 1D barcodes (EAN13, CODE128, CODE39) and 2D codes (QR Code, PDF417, Data Matrix), meeting diverse identification needs.
It features USB and Bluetooth interfaces for easy connection to various device.. It supports standard printer command languages like ESC/POS and TSC/TSPL, ensuring broad software compatibility.
With dimensions of 140(L) x 95(W) x 93(H) mm and a weight of 680g (excluding paper roll), it saves valuable counter space while being solidly built.
Ideal for printing price tags, shelf labels, and promotional stickers for larger items.
Perfect for generating shipping labels, packing slips, and inventory control tags that require durability and fast printing.
Suitable for product identification, batch coding, and compliance labeling on the production line.
Product Parameters
| Printing Method | Thermal Line |
| Resolution | Thermal Line 8 dots/mm |
| Printing Speed | 150mm/s |
| Effective Printing Width | 72mm |
| TPH | 50km |
| Paper Width | Max:80±0.5mm/ Min: 40±0.5mm |
| Paper Type | Folded Paper/Thermal Label Paper/Normal Thermal Paper |
| Commands | ESC/POS, CPCL, TSPL |
| Paper Thickness | 0.12~0.20mm(Thermal Label Paper) |
| Driver | Windows/Linux/Android |
| Print Font | Codepage,: ANK: 9 x17 / 12 x24; Chinese: 24 x 24 |
| Barcode | 1D: UPC-A、UPC-E、EAN-13、EAN-8、CODE39、ITF25、CODABAR、 CODE93、CODE128 |
| 2D: PDF417、QR Code、DATA Matrix | |
| Interface | USB / USB+Bluetooth(2.0/4.0) |
| Power Supply | DC24V±10％, 2A |
| Operating Temp/Humidity | 0～50℃/10～80% |
| Outline Dimension | 140x95x93mm(L×W×H) |
| Storage Temp/Humidity | -20～60℃/10～90% |
