SP-DVII
SPRT
Product Parameters
| Printing Method | Dot Matrix | |
| Printing Speed | 1.2 lines/s (16 Character/line), 0.7 lines/s ( Character/line), 0.4 lines/s (40 Character/line) | |
| Effective Printing Width | 33mm/48mm | |
| Character | Character Set | ASCII, GB18030(Chinese) |
| Print Font | ASCII: 6×7; Chinese:16×16, 12×12 | |
| Character per Line | 16/24/40 | |
| Paper Spec | Paper Type | Plain paper |
| Paper Width | 44.5± 0.5mm/ 57.5± 0.5mm | |
| Paper Thickness | 0.05~0.08mm | |
| Paper Roll Diameter | Max: 40.0mm | |
| Roll Core Inner Diameter | 13mm(min.) | |
| Barcode | N/A | |
| Emulation | ESC/POS | |
| Driver | Windows98/2000/NT/XP/Vista/Win7 | |
| Interface | RS-232/Parallel | |
| Paper Supply Method | Semi-auto paper loading | |
| Power Supply (Adapter) | DC5V, 1.5A | |
| Printer Mechanism | EPSON Brand | |
| Auto cutter | Type | N/A |
| Life | ||
| Cutting Method | ||
| Physical | Outline Dimension (WxHxD) | 111 x 63.5 x 68mm |
| Installation Port Size (WxHxD) | 103.5 x 57.5mm (W xH), Depth: 68mm | |
| Color | Beige | |
| Weight | 244g | |
| Environment | Operating Temp | 0~ 50 °C |
| Operating Humidity | 10%~80% | |
Product Description
SP-DVII is an innovative dot matrix printer designed with a drawer-style door mechanism that significantly simplifies and streamlines the paper replacement process for users. This creative design enhances operational convenience and reduces downtime. Utilizing impact dot matrix printing technology, the DVII ensures reliable and durable output on multi-part forms, making it ideal for receipts, invoices, and transaction records. It offers flexible paper compatibility by supporting two standard paper widths—58mm and 44mm—providing users with adaptable options to meet varying application needs.
Designed for quick setup and consistent long-term operation with minimal maintenance.
Enables effortless loading and replacement of paper rolls and ribbons, reducing downtime.
Ensures stable performance even in electrically noisy environments.
Supports high-capacity paper rolls to meet continuous and high-volume printing demands.
The compact printer series offers versatile size and functional options tailored for diverse industrial and commercial uses, primarily supporting POS receipt printing and test result output with instruments.
The 58mm model with auto cutter is ideal for fire safety wall-mounted controllers (e.g., in hotels and retail stores), medical diagnostic devices, and environmental monitoring equipment. The 58mm model with auto cutter suits self-service kiosks, bank card terminals, and health monitoring devices such as blood pressure monitors. Meanwhile, the 80mm model with auto cutter is commonly applied in medical check-in systems, bank queue machines, self-service terminals, visitor systems, and point-of-sale machines, delivering reliable performance across automated and transactional environments.
