RME4
Product Description
SP-RME4 is a high-performance thermal printer designed for self-service terminals, featuring an extra-large paper compartment that supports 80mm diameter paper rolls. With its low-paper alert function, it significantly reduces maintenance frequency. The printer incorporates a jam-proof cutter design and supports both full-cut and partial-cut modes, ensuring continuous and stable paper output. It offers dual USB and serial interfaces for flexible connectivity and a front-mount installation method for easy integration and upkeep. Adaptable to a wide range of embedded systems across various industries, it provides a reliable and efficient printing solution for diverse unattended applications.
Equipped with an automatic cutter and a jam-proof blade design, ensuring smooth and trouble-free receipt separation for continuous and stable operation.
Features a large-capacity paper compartment to effectively reduce paper replacement frequency, along with a paper-low warning function for proactive maintenance planning.
Supports printing of both 1D and 2D barcodes, making it widely applicable in various scenarios such as self-service machines and cash registers.
The compact printer series offers versatile size and functional options tailored for diverse industrial and commercial uses, primarily supporting POS receipt printing and test result output with instruments.
The 58mm model with auto cutter is ideal for fire safety wall-mounted controllers (e.g., in hotels and retail stores), medical diagnostic devices, and environmental monitoring equipment. The 58mm model with auto cutter suits self-service kiosks, bank card terminals, and health monitoring devices such as blood pressure monitors. Meanwhile, the 80mm model with auto cutter is commonly applied in medical check-in systems, bank queue machines, self-service terminals, visitor systems, and point-of-sale machines, delivering reliable performance across automated and transactional environments.
Product Parameters
| Printing Method | Thermal Line | ||
| Printing Speed | 170 mm/s | ||
| Resolution | 8 dots/mm (203dpi) | ||
| Effective Printing Width | 48mm/72mm | ||
| Character | Character Set | ASCII, GB18030(Chinese), BIG5 | |
| Print Font | Codepage, ANK:12×24; Chinese: 24×24 | ||
| Character per Line | 48/72 | ||
| Paper Spec | Paper Type | Thermal paper | |
| Paper Width | 57.5± 0.5mm/79.5± 0.5mm | ||
| Paper Thickness | 0.06~0.08mm | ||
| Paper Roll Diameter | Max: 80.0mm | ||
| Roll Core Inner Diameter | 13mm(min.) | ||
| Reliability | MCBF | 1 million lines | |
| Barcode | 1D: UPC-A,UPC-E,EAN-13,EAN-8,CODE39,ITF25,CODEBAR,CODE93,CODE128 | ||
| 2D: PDF417、QRCODE、DATAMATRIX | |||
| Emulation | ESC/POS | ||
| Driver | Windows/JPOS/OPOS/Linux/Android | ||
| Interface | RS-232+USB | ||
| Paper Supply Method | Drop-in easy paper loading | ||
| Power Supply (Adapter) | DC24V, 2A | ||
| Printer Mechanism | SEIKO Brand | ||
| Auto cutter | Type | Guillotine | |
| Life | 1,000,000 | ||
| Cutting Method | Partial Cut/ Full cut | ||
| Physical | Outline Dimension (WxHxD) | 132×125.5x87mm | |
| Installation Depth | 81.5mm | ||
| Color | Black/White | ||
| Weight | 400g | ||
