SP-RME3
SPRT
Product Parameters
| Printing Method | Thermal Line | |
| Printing Speed | 100mm/s | |
| Resolution | 8 dots/mm, 384 dots/line | |
| Effective Printing Width | 48mm | |
| Character | Character Set | ASCII, GB18030(Chinese), BIG5 (24*24) |
| Print Font | Codepage, ASCII 9×24, 12×24 | |
| Character per Line | 32 | |
| Paper Spec | Paper Type | Thermal paper |
| Paper Width | 57.5± 0.5mm | |
| Paper Thickness | 0.06~0.08mm | |
| Paper Roll Diameter | Max: 60.0mm | |
| Roll Core Inner Diameter | 13mm(min.) | |
| Reliability | MCBF | 5 million lines |
| Barcode | UPC-A，UPC-E，EAN-13，EAN-8，CODE39，ITF25，CODEBAR，CODE93，CODE128 | |
| Emulation | ESC/POS | |
| Driver | Windows98/2000/NT/XP/Vista/Win7/Win8 | |
| Interface | RS-232/Parallel/USB/RS-485 | |
| Paper Supply Method | Drop-in easy paper loading | |
| Power Supply (Adapter) | DC9~24V±10％, 2A | |
| Printer Mechanism | SEIKO Brand | |
| Auto cutter | Auto cutter | Guillotine |
| Life | 1,000,000 cuts | |
| Cutting Method | Full / Partial cut | |
| Environment | Outline Dimension (WxHxD) | 110x101x70.5mm |
| Installation Port Size (WxHxD) | 103.5 x 95.5x 67.5mm | |
| Color | Black | |
| Weight | 334g | |
Product Description
This product is a 58mm thermal printer designed for commercial applications. Its large paper compartment supports extended continuous use, reducing the frequency of paper reloads. High-speed printing ensures operational efficiency, while the automatic cutter guarantees clean and precise cutting of labels and receipts. An imported print mechanism is available as an option, further enhancing the durability of the printhead and output quality. Suitable for retail checkout, ticket printing, label printing, and various service scenarios, it integrates stability, efficiency, and convenience in a compact and reliable design.
Reduces waiting time significantly, delivering efficiency and reliability for seamless customer experience.
Features a wide-opening paper cover for easy access and smooth operation.
Supports multiple interfaces including Serial (RS232/RS485), Parallel, and USB for flexible integration.
The compact printer series offers versatile size and functional options tailored for diverse industrial and commercial uses, primarily supporting POS receipt printing and test result output with instruments.
The 58mm model with auto cutter is ideal for fire safety wall-mounted controllers (e.g., in hotels and retail stores), medical diagnostic devices, and environmental monitoring equipment. The 58mm model with auto cutter suits self-service kiosks, bank card terminals, and health monitoring devices such as blood pressure monitors. Meanwhile, the 80mm model with auto cutter is commonly applied in medical check-in systems, bank queue machines, self-service terminals, visitor systems, and point-of-sale machines, delivering reliable performance across automated and transactional environments.
