SP-RME6
SPRT
Product Parameters
| Printing Method | Thermal Line |
| Resolution | 8 dots/mm, 384 dots/line |
| Printing Speed | 100mm/s (MAX) |
| Effective Printing Width | 48mm |
| Paper Width | 57.5mm±0.5mm |
| Graphic Printing | Support dot matrix graphics,curve printing |
| Print Font | ASCIl:12x24,9x7,GB18030, BIG5, |
| Barcode | 1D: UPC-A, UPC-E, EAN-13, EAN-8, CODE39, ITF25, CODABAR, CODE93, CODE128; |
| 2D: PDF417, QR Code, DATA Matrix | |
| Interface | USB+Serial |
| Supported Functions | Paper out warning, overheating protection |
| Power Supply | DC 9V-24V 2A,12V-24V 2A is highly recommended |
| Paper | Normal Thermal Paper 58XΦ50mm (MAX) |
| Paper Thickness | 0.06-0.08mm |
| Paper Loading Method | Simple Paper Loading |
| Paper Cutting Method | Automatically Cutting(full-cut and half-cut mode） |
| Installation Size | 96.7mmx95.7mm(WxH) Depth:52.7mm |
| Dimensions | 100.3mm×99.9mm×60mm(WxHXD) |
| Operating Temp/Humidity | 0~50°C/10~80% |
| Storage Temp/Humidity | -20-60°C/10-90% |
| TPH | 50KM |
| Life Of Cutter | 1,000,000 cuts |
Product Description
The SP-E6 is a 58mm ultra-compact printer featuring an integrated auto-cutter. With its sleek and minimalist design, this space-saving device comes in two elegant color options: glossy white and glossy black. It is engineered for seamless integration into various self-service terminals and can be fully controlled via command sets. Offering both full and partial cutting modes, it provides exceptional operational flexibility. Built for durability, its cutting mechanism boasts an impressive lifespan of up to 1 million cycles, ensuring reliable long-term performance for continuous high-volume printing applications.
Engineered for high-volume operations, it features an auto-cutter with a 1-million-cycle lifespan (full/half-cut) and a 50km printhead lifespan, ensuring consistent, long-term performance.
Offers a fast printing speed of 100mm/s, significantly boosting transaction processing and workflow efficiency.
Capable of printing barcodes, QR codes, and custom fonts. Its integrated interface supports secondary development for seamless system integration.
Comes standard with dual USB + Serial Port interfaces, providing more flexible and reliable connections than older single-interface models.
The compact printer series offers versatile size and functional options tailored for diverse industrial and commercial uses, primarily supporting POS receipt printing and test result output with instruments.
The 58mm model with auto cutter is ideal for fire safety wall-mounted controllers (e.g., in hotels and retail stores), medical diagnostic devices, and environmental monitoring equipment. The 58mm model with auto cutter suits self-service kiosks, bank card terminals, and health monitoring devices such as blood pressure monitors. Meanwhile, the 80mm model with auto cutter is commonly applied in medical check-in systems, bank queue machines, self-service terminals, visitor systems, and point-of-sale machines, delivering reliable performance across automated and transactional environments.
